집 > 상품 > 유기 비료 생산 라인 > Potassium Sulfate Granulation Press Line with Dry Compaction Technology for High-Pressure Heavy Compaction and No Drying Process Required

Potassium Sulfate Granulation Press Line with Dry Compaction Technology for High-Pressure Heavy Compaction and No Drying Process Required

Name: Potassium Sulfate Granulation Press Line with Dry Compaction Technology for High-Pressure Heavy Compaction and No Drying Process Required
Brand: ZHENGZHOU SHENGHONG HEAVY INDUSTRY TECHNOLOGY CO., LTD.
SKU: SDZ 시리즈
Price: 17,799.00 USD
Availability: InStock

제품 세부 정보

원래 장소: 중국 허난성 정저우

브랜드 이름: Shenghong

인증: SGS, ISO, BV

모델 번호: SDZ 시리즈

지불 및 배송 조건

최소 주문 수량: 1세트

가격: can be negotiated

포장 세부 사항: 컨테이너 또는 합판 상자

배달 시간: 10~15일

지불 조건: 신용장, 티/티

공급 능력: 달 당 200 세트

최상의 가격을 얻으세요

제품 세부 정보

제품 설명

제품 세부 정보

강조하다:

기능:	NPK 복합 비료 펠렛 생산	응용분야:	농산물
모터:	당신이 요청한대로	과립 모양:	가루
펠릿 비율:	98% 이상	용량:	시간당 1-20톤

기능:	NPK 복합 비료 펠렛 생산
응용분야:	농산물
모터:	당신이 요청한대로
과립 모양:	가루
펠릿 비율:	98% 이상
용량:	시간당 1-20톤

제품 설명

Potassium Sulfate & Potassium Chloride Granulation Press Line

Product Introduction: As a professional fertilizer machinery manufacturer, we supply the turnkey Potassium Sulfate & Potassium Chloride Granulation Press Line to meet the rising global demand for upgrading potash powders into premium granular forms. Utilizing advanced dry compaction technology, this high-performance compound fertilizer line transforms raw Potassium Sulfate (SOP) and Potassium Chloride (MOP) powder into high-density, uniform granules without adding water or binders. Equipped with a heavy-duty Potash fertilizer granulator and MOP compaction machine, this SOP fertilizer production line is your ideal industrial solution to eliminate dust, reduce nutrient loss, and maximize your factory ROI.

Key Performance Features

Ultra-Wear-Resistant Roller Design: Since potash crystals are highly abrasive, our Potash fertilizer granulator features customized rollers made of heavy-duty manganese alloy or special chrome-molybdenum alloy to ensure an extended operational lifespan.
High-Pressure Heavy Compaction: The integrated MOP compaction machine provides enormous hydraulic pressure, ensuring fine potash crystal powder compaction achieves maximum density and excellent granule hardness.
No Drying Process Required: Operating as a true non-drying system, this SOP fertilizer production line works with raw materials under 5% moisture content, eliminating the need for high-energy dryers and slashing coal or gas costs.
High One-Time Molding Rate: The advanced counter-rotating roller mechanism guarantees a granulation rate of over 90%, directly outputting robust, non-caking finished potash particles in a single pass.

Technical Specifications

Production Capacity: 3 - 10 Tons/Hour (Customizable based on your industrial potash processing needs)
Granulation Method: Double-Roller Dry Extrusion Compaction & Flaking
Target Raw Materials: Potassium Sulfate (SOP), Potassium Chloride / Muriate of Potash (MOP)
Finished Granule Size: 2mm - 6mm Ball, Tablet, or Irregular Angular shapes (Adjustable based on regional market demand)
Roller Sheet Material: Anti-wear chrome-molybdenum steel or heavy-duty hardened manganese alloy

8-Stage Step-by-Step Working Principle

The entire process flow of this high-capacity MOP compaction machine and SOP fertilizer production line is scientifically laid out to guarantee continuous, automated, and trouble-free operation:

Smart Raw Material Batching: The automated dosing and batching system precisely weighs Potassium Sulfate or Potassium Chloride and necessary binder/additive powders according to your specific potash formula ratios.
Homogeneous Material Mixing: Industrial vertical or horizontal mixers blend the dry potash raw materials uniformly to improve the overall chemical balance and fertilizer consistency of the final product.
Double-Roller Extrusion Granulation: The core machine—the heavy-duty Potash fertilizer granulator—forces the fine powder through two counter-rotating rollers under extreme hydraulic pressure. The potash powder is instantly compacted into dense flakes and then mechanically crushed into raw granules.
Particle Drying (Energy-Saving Option): For custom formulas requiring ultra-low moisture storage, granules can pass through a rotary dryer. Note: For standard dry potash formulations, this energy-consuming step can be completely bypassed to optimize your production costs.
High-Efficiency Particle Cooling: Hot fertilizer particles from the extrusion phase are cooled in a heavy-duty rotary cooling machine to eliminate thermal stress and caking, preparing them for immediate packaging.
Precision Particle Classification & Screening: A heavy-duty rotary screening machine grades the cooled potash particles. Qualified products (2-4mm) move to the coating stage, while oversized and undersized dust are automatically returned via belt conveyor for re-compaction, ensuring 100% material utilization.
Finished Product Coating: Qualified potash granules enter the rotary coating drum, where an anti-caking agent or oil coating is applied to increase the brightness, roundness, and shelf-life of the commercial product in humid climates.
Automated Weighing & Packaging: The final film-coated potash particles are automatically weighed, packed into 25kg or 50kg bags, and sealed, ready for direct international shipment or warehouse storage.

Get a Free Potash Fertilizer Line Project Layout Design: Are you looking for a reliable fertilizer plant manufacturer? Tell our engineering experts your raw materials and target hourly capacity. We will provide a customized factory blueprint and wholesale price quote within 24 hours! Inquire now for factory direct pricing.
